Abaco Systems / VMIC VMIVME-1110-1-24-11-1-1 64-Bit High-Voltage Digital Input Board
- Model
- Abaco Systems / VMIC VMIVME-1110-1-24-11-1-1
- Calibration
- Available on request
- Price
- $1,099
- Status
- In stock
- RFQ ref
- VMIVME-1110-1-24-11-1-1
This unit
The Abaco Systems VMIVME-1110-1-24-11-1-1 is a 64-bit high-voltage digital input board for VMEbus systems that acquires and conditions digital signals from diverse sources including electronic switching circuits, logic circuits, mechanical contacts, relay contacts, and signal conditioning modules. The board delivers 8-, 16-, and 32-bit data transfer modes with configurable input signal conditioning supporting both current sink and voltage source topologies. Integrated input filters and hysteresis optimize signal integrity across varied industrial and test environments.
• Product: VMIVME-1110-1-24-11-1-1 64-Bit High-Voltage Digital Input Board
• Manufacturer: Abaco Systems / VMIC
• Bus Interface: VMEbus compatible
• Data Transfer Modes: 8-bit, 16-bit, and 32-bit
• Input Signal Conditioning: High-voltage current sink and voltage source configurations with selectable input filters and built-in hysteresis
• Memory Architecture: Contiguous I/O address support with dual board address switches enabling efficient CSR and I/O address mapping
• Diagnostics: Built-in-test (BIT) logic with front-panel Fail LED
• Access Type: Jumper-selectable for supervisory or non-privileged short I/O memory space (factory-configured for short supervisory I/O)
Key Features
• Accommodates high-voltage digital signals from multiple source types
• Dual address switch sets for flexible memory mapping across multi-board subsystems
• Contiguous CSR addressing capability for efficient register organization
• Front-panel Fail LED provides immediate fault visibility
• Built-in diagnostic logic accelerates troubleshooting
Typical Applications Industrial control systems, test equipment integration, relay and switch monitoring, high-voltage signal acquisition, and VMEbus-based data acquisition platforms requiring configurable input conditioning.
Compatibility & Integration Full VMEbus compliance. Supports integration with Abaco Systems Megamodule family subsystems. Operable in supervisory and non-privileged I/O memory spaces with factory-selectable jumper configuration.
