401850 REV A Digital Lightwave NGMR2 Board for Digital Lightwave NIC NXG
401850 REV A,Digital Lightwave NGMR2 board designed for use with the NIC NXG platform. Supports advanced network testing and monitoring functions for high-speed telecom environments. Ideal for service provider test applications where modular, field-upgradable architecture is essential. Enables flexible expansion of transport network test capabilities with reliable hardware performance.
- Model
- Digital Lightwave 401850 REV A
- Calibration
- Available on request
- Price
- $1,480
- Status
- In stock
- RFQ ref
- 401850 REV A
This unit
The 401850 REV A Digital Lightwave NGMR2 Board is a modular, field-upgradable component engineered for the Digital Lightwave NIC NXG platform. It delivers advanced network testing and monitoring capabilities optimized for high-speed telecommunications environments. The NGMR2 architecture supports flexible expansion of transport network test functions through license-based test options, enabling service providers to scale testing capabilities as network requirements evolve.
Technical Specifications
Product Name: 401850 REV A Digital Lightwave NGMR2 Board Platform Compatibility: Digital Lightwave NIC NXG Architecture: Modular, field-upgradable Multi-Rate (NGMR) module Performance Environment: Reliable hardware performance in high-speed telecommunications applicationsKey Features
- License-based test options enable protocol-specific functionality without hardware replacement
- Reconfigurable module design supports dynamic capability expansion
- Multi-protocol support across SONET/SDH, OTN, and Ethernet standards
- SONET/SDH operation at 51 Mbps, 155 Mbps, 622 Mbps, 2.5 Gbps, and 10 Gbps
- OTN support includes OTU-1 (2.66G), OTU-2 (10.7G), OTU4, OTU3, OTU3e1/OTU3e2, OTU2f/OTU1f, OTU2e/OTU1e, OTU2, and OTU1 configurations
- ODU multiplexing with simultaneous generation and analysis across all levels, including ODU0 and ODUflex
- Complete OTN overhead manipulation and analysis with byte capture for trace and MSI bytes
- Ethernet support from 10M to 10G on NIC Plus NXG platforms
- 1G Ethernet, 10G Ethernet FEC (11.049/11.095G), 10G Ethernet LAN (10.3G), and 10G Ethernet WAN (9.9953G) test options
- Virtual Concatenation (VCAT) test options for high-order and low-order configurations
- Link Capacity Adjustment Scheme (LCAS) support
- Multi-Channel generation and analysis for OTU1 and OTU2
Typical Applications
- Service provider transport network testing
- High-speed optical signal validation
- Multi-protocol network analysis and monitoring
- Field-based network expansion and upgrades
Compatibility & Integration The NGMR2 board integrates directly into the NIC NXG platform's software-based architecture. Its modular design enables scalable test capability deployment aligned with evolving network technologies and capacity demands.
Digital Lightwave 401850 REV A — Repair & Calibration Service
Aumictech offers NIST-traceable calibration and repair for the Digital Lightwave 401850 REV A. All calibrations are performed to NIST-traceable standards and ship with a certificate. Turnaround is typically 1–3 business days after receipt.
Digital Lightwave 401850 REV A price
This Digital Lightwave 401850 REV A is listed at $1,480. Calibration is available separately from $450. Contact us for volume pricing or if you need multiple units.
Digital Lightwave 401850 REV A calibration cost
NIST-traceable calibration for the Digital Lightwave 401850 REV A is $450 (standard — pass/fail certificate and calibration sticker) or $650 (full measured data at every test point, reference standards documented, traceability chain included). Turnaround is 1 to 3 business days after receipt. See full calibration details →
