Kepco BHK1000-0.2M

The Kepco BHK1000-0.2M is a 200 W DC power supply delivering 0–1000 V at 0–0.2 A with voltage and current stabilization and automatic crossover. Built on a hybrid architecture combining vacuum tube series control with solid-state reference and amplifier stages, this full-rack unit operates from single-phase AC input (105–126 V or 210–250 V AC, 50–65 Hz) and supports both local keypad control and remote programming via analog terminal strips or IEEE 488.2 GPIB interface. The unit features 12-bit control resolution, FET output stage, dual fusing protection (AC and DC), and operates across –20°C to +55°C ambient conditions. Output voltage displays to one decimal place; output current displays to three decimals. Selectable fast response mode disconnects output capacitance for improved transient performance in current source or rapidly programmed applications. The supply meets EN61010-1 safety requirements and carries CE certification.

Technical Specifications

Output: 0–1000 V DC, 0–0.2 A DC; 200 W total

Regulation: Voltage and current stabilized with automatic crossover

Input: 105–126 V AC or 210–250 V AC, single phase, 50–65 Hz

Programming: 12-bit control resolution across 0–10% of current rating

Isolation: 1000 V DC (or p-p) plus maximum rated output voltage between chassis and either output terminal

Operating Temperature: –20°C to +55°C ambient; –40°C to +85°C storage

Output Display: Voltage to 0.1 V; current to 0.001 A

Key Features

Hybrid vacuum tube/solid-state design with FET output stage

Dual operating modes: conventional filtering or fast response (capacitor disconnect)

Local control via front-panel keypad

Remote analog control via dual 10-position rear terminal strips

IEEE 488.2 GPIB digital interface (24-pin female connector)

AC and DC fusing; overload and short-circuit protection

CE mark and EN61010-1 compliance

Typical Applications Precision industrial test, measurement, and laboratory environments requiring high-voltage, low-current stabilized DC output with programmable control and rapid transient response.

Compatibility & Integration Full-rack form factor (17" W × 15.90" D × 5.218" H). Analog and digital programming support simultaneous local and remote operation.
